Hard-coded implementation of ItoPlasmaPhysics for simplified discharges in STP air. @detail Transport data for the electrons are taken from BOLSIG+. More...

#include <CD_ItoPlasmaAir3LFA.H>

Inheritance diagram for Physics::ItoPlasma::ItoPlasmaAir3LFA:

[legend]

Collaboration diagram for Physics::ItoPlasma::ItoPlasmaAir3LFA:

[legend]

Classes
class	Electron
	Electron species. More...

class	Negative

class	PhotonZ

class	Positive
	Positive ion species. More...

Public Member Functions
	ItoPlasmaAir3LFA ()
	Full constructor. Initializes species and sets up reactions.

virtual	~ItoPlasmaAir3LFA ()
	Destructor. Does nothing of importance.

virtual void	parseRuntimeOptions () noexcept override
	Parse run-time options.

virtual Real	computeDt (const RealVect a_E, const RealVect a_pos, const Vector< Real > a_densities) const noexcept override
	Compute a physics-baseded time step. More...

virtual Real	computeAlpha (const RealVect a_E) const override
	Compute Townsend ionization coefficient. More...

virtual void	updateReactionRates (const RealVect a_E, const Real a_dx, const Real a_kappa) const noexcept override
	Update reaction rates. More...

Vector< Real >	computeItoMobilities (const Real a_time, const RealVect a_pos, const RealVect a_E) const noexcept override
	Compute the Ito solver mobilities. More...

Vector< Real >	computeItoDiffusion (const Real a_time, const RealVect a_pos, const RealVect a_E) const noexcept override
	Compute the Ito solver diffusion coefficients. More...

void	injectParticlesEB (Vector< List< ItoParticle >> &a_outgoingParticles, Vector< List< Photon >> &a_outgoingPhotons, const Vector< List< ItoParticle >> &a_incomingParticles, const Vector< List< Photon >> &a_incomingPhotons, const Vector< FPR > &a_newNumParticles, const Vector< FPR > &a_oldNumParticles, const RealVect &a_E, const RealVect &a_cellCenter, const RealVect &a_cellCentroid, const RealVect &a_bndryCentroid, const RealVect &a_bndryNormal, const Real a_bndryArea, const Real a_dx, const Real a_dt, const bool a_isDielectric, const int a_matIndex) const noexcept override
	Resolve particle and photon injection at the EB. More...

Public Member Functions inherited from Physics::ItoPlasma::ItoPlasmaPhysics
	ItoPlasmaPhysics ()
	Constructor. Does nothing.

virtual	~ItoPlasmaPhysics ()
	Destructor. Does nothing.

const Vector< RefCountedPtr< ItoSpecies > > &	getItoSpecies () const
	Get all particle species. More...

const Vector< RefCountedPtr< RtSpecies > > &	getRtSpecies () const
	Get all photon species. More...

int	getNumPlasmaSpecies () const
	Return number of ion equations.

int	getNumPhotonSpecies () const
	Return number of RTE equations.

virtual Real	initialSigma (const Real a_time, const RealVect a_pos) const
	Set initial surface charge. Default is 0, override if you want. More...

void	advanceKMC (Vector< FPR > &a_numParticles, Vector< FPR > &a_numNewPhotons, const Real a_dt, const RealVect a_E, const Real a_dx, const Real a_kappa) const
	Advance particles. More...

void	reconcileParticles (Vector< List< ItoParticle > * > &a_particles, const Vector< FPR > &a_newNumParticles, const Vector< FPR > &a_oldNumParticles, const RealVect a_cellPos, const RealVect a_centroidPos, const RealVect a_lo, const RealVect a_hi, const RealVect a_bndryCentroid, const RealVect a_bndryNormal, const Real a_dx, const Real a_kappa) const noexcept
	Reconcile the number of particles. More...

void	reconcilePhotons (Vector< List< Photon > * > &a_newPhotons, const Vector< FPR > &a_numNewPhotons, const RealVect a_cellPos, const RealVect a_centroidPos, const RealVect a_lo, const RealVect a_hi, const RealVect a_bndryCentroid, const RealVect a_bndryNormal, const Real a_dx, const Real a_kappa) const noexcept
	Generate new photons. More...

void	reconcilePhotoionization (Vector< List< ItoParticle > * > &a_particles, const Vector< List< Photon > * > &a_absorbedPhotons) const noexcept
	Reconcile photoionization reactions. More...

Protected Member Functions
virtual Real	excitationRates (const Real a_E) const
	Excitation rate for photoionization term.

virtual Real	sergeyFactor (const Real a_O2frac) const
	Sergey factor for photoionization term.

virtual void	addTable (const std::string a_tableName, const std::string a_file) noexcept
	Add a table to m_tables. More...

virtual void	readTables () noexcept
	Read various tabulated data into the lookup tables in this class.

virtual void	parseDx () noexcept
	Parse the m_dX variable used for time step restriction.

virtual void	parseTransport () noexcept
	Parse some auxiliary transport settings.

Protected Member Functions inherited from Physics::ItoPlasma::ItoPlasmaPhysics
void	defineKMC () noexcept
	Define the KMC solver and state.

void	parsePPC () noexcept
	Parse the maximum number of particles generated per cell.

void	parseDebug () noexcept
	Parse the maximum number of particles generated per cell.

void	parseAlgorithm () noexcept
	Parse reaction algorithm.

void	removeParticles (List< ItoParticle > &a_particles, const long long a_numToRemove) const
	Remove particles from the input list. More...

Protected Attributes
bool	m_extrapBC
	Extrapolate BC or not.

Real	m_deltaX
	User-defined parameter for time step restriction.

int	m_numPlasmaSpecies
	Number of plasma species.

int	m_numRtSpecies
	Number of radiative transfer species.

Real	m_ionMobility
	Ion mobility.

Real	m_ionDiffCo
	Ion diffusion coefficient.

Real	m_ionImpactEfficiency
	Ion impact efficiency.

Real	m_quantumEfficiency
	Quantum efficiency.

Real	m_N
	Neutral number density.

Real	m_p
	Gas pressure (SI)

Real	m_pq
	Quenching pressure (SI)

Real	m_T
	Gas temperature.

Real	m_O2frac
	O2 content.

Real	m_N2frac
	N2 content.

Real	m_photoIonizationFactor
	Photo-ionization factor.

std::map< std::string, LookupTable1D< 2 > >	m_tables
	Lookup tables holding mobilities, rate coefficients etc.

Protected Attributes inherited from Physics::ItoPlasma::ItoPlasmaPhysics
Algorithm	m_algorithm
	Algorithm to use for KMC advance.

ParticlePlacement	m_particlePlacement
	Particle placement algorithm.

std::string	m_className
	Class name. Used for options parsing.

bool	m_debug
	Turn on/off debugging.

KMCState	m_kmcState
	Kinetic Monte Carlo state.

KMCSolverType	m_kmcSolver
	Kinetic Monte Carlo solver.

std::vector< std::shared_ptr< const KMCReaction > >	m_kmcReactions
	List of reactions for the KMC solver.

std::vector< std::shared_ptr< const ItoPlasmaPhotoReaction > >	m_photoReactions
	List of photoionization reactions.

Vector< RefCountedPtr< ItoSpecies > >	m_plasmaSpecies
	List of solver-tracked particle species.

Vector< RefCountedPtr< RtSpecies > >	m_rtSpecies
	List of solver-tracked photon species.

int	m_maxNewParticles
	Maximum new number of particles generated by the chemistry advance.

int	m_maxNewPhotons
	Maximum new number of photons generated by the chemistry advance.

int	m_Ncrit
	Solver setting for the Cao et. al algorithm. More...

int	m_NSSA
	Solver setting for the Cao et. al algorithm. More...

Real	m_SSAlim
	Solver setting for the Cao et. al. algorithm. More...

Real	m_eps
	Solver setting for the Cao et. al. algorithm. More...

Additional Inherited Members
Protected Types inherited from Physics::ItoPlasma::ItoPlasmaPhysics
enum class	Algorithm { SSA , Tau , Hybrid }
	Enum for switching between KMC algorithms. More...

enum class	ParticlePlacement { Random , Centroid }
	Enum for switching between various particle placement algorithms.

Detailed Description

Hard-coded implementation of ItoPlasmaPhysics for simplified discharges in STP air. @detail Transport data for the electrons are taken from BOLSIG+.

Member Function Documentation

◆ addTable()

void ItoPlasmaAir3LFA::addTable	(	const std::string	a_tableName,
		const std::string	a_file
	)

protectedvirtualnoexcept

Add a table to m_tables.

Parameters

[in]	a_tableName	Table identifier for m_table
[in]	a_file	File. Must be in column x/y format

◆ computeAlpha()

Real ItoPlasmaAir3LFA::computeAlpha ( const RealVect a_E ) const

overridevirtual

Compute Townsend ionization coefficient.

Parameters

[in] a_E Electric field.

Implements Physics::ItoPlasma::ItoPlasmaPhysics.

◆ computeDt()

Real ItoPlasmaAir3LFA::computeDt	(	const RealVect	a_E,
		const RealVect	a_pos,
		const Vector< Real >	a_densities
	)		const

overridevirtualnoexcept

Compute a physics-baseded time step.

Parameters

[in]	a_E	Electric field.
[in]	a_pos	Position
[in]	a_numParticles	Number of particles per cell

Returns: Returns m_deltaX/k where k is Townsend ionization coefficient and m_deltaX is user-specified.

Reimplemented from Physics::ItoPlasma::ItoPlasmaPhysics.

◆ computeItoDiffusion()

Vector< Real > ItoPlasmaAir3LFA::computeItoDiffusion	(	const Real	a_time,
		const RealVect	a_pos,
		const RealVect	a_E
	)		const

overridevirtualnoexcept

Compute the Ito solver diffusion coefficients.

Parameters

[in]	a_time	Time
[in]	a_pos	Position
[in]	a_E	Electric field

Implements Physics::ItoPlasma::ItoPlasmaPhysics.

◆ computeItoMobilities()

Vector< Real > ItoPlasmaAir3LFA::computeItoMobilities	(	const Real	a_time,
		const RealVect	a_pos,
		const RealVect	a_E
	)		const

overridevirtualnoexcept

Compute the Ito solver mobilities.

Parameters

[in]	a_time	Time
[in]	a_pos	Position
[in]	a_E	Electric field

Implements Physics::ItoPlasma::ItoPlasmaPhysics.

◆ injectParticlesEB()

void ItoPlasmaAir3LFA::injectParticlesEB	(	Vector< List< ItoParticle >> &	a_outgoingParticles,
		Vector< List< Photon >> &	a_outgoingPhotons,
		const Vector< List< ItoParticle >> &	a_incomingParticles,
		const Vector< List< Photon >> &	a_incomingPhotons,
		const Vector< FPR > &	a_newNumParticles,
		const Vector< FPR > &	a_oldNumParticles,
		const RealVect &	a_E,
		const RealVect &	a_cellCenter,
		const RealVect &	a_cellCentroid,
		const RealVect &	a_bndryCentroid,
		const RealVect &	a_bndryNormal,
		const Real	a_bndryArea,
		const Real	a_dx,
		const Real	a_dt,
		const bool	a_isDielectric,
		const int	a_matIndex
	)		const

overridevirtualnoexcept

Resolve particle and photon injection at the EB.

Routine is here to handle charge injection, secondary emission etc.

Parameters

[out]	a_outgoingParticles	Outgoing plasma species particles.
[out]	a_outgoingPhotons	Photons injected through the EB
[in]	a_incomingParticles	Particles that left the computational domain through the EB
[in]	a_incomingPhotons	Photons that left the computational domain through the EB
[in]	a_electricField	Electric field
[in]	a_cellCenter	Physical position of the cell center.
[in]	a_cellCentroid	Cell centroid relative to the cell center (not multiplied by dx)
[in]	a_bndryCentroid	EB face centroid relative to the cell center (not multiplied by dx)
[in]	a_bndryNormal	Cut-cell normal vector.
[in]	a_bndryArea	Cut-cell boundary area - not multiplied by dx (2D) or dx^2 (3D)
[in]	a_dx	Grid resolution on this level.
[in]	a_dt	Time step
[in]	a_isDielectric	Dielectric or electrode.
[in]	a_matIndex	Material index (taken from computationalGeometry)

Implements Physics::ItoPlasma::ItoPlasmaPhysics.

◆ updateReactionRates()

void ItoPlasmaAir3LFA::updateReactionRates	(	const RealVect	a_E,
		const Real	a_dx,
		const Real	a_kappa
	)		const

overridevirtualnoexcept

Update reaction rates.

Parameters

[in]	a_E	Electric field
[in]	a_dx	Grid resolution
[in]	a_kappa	Cut-cell volume fraction

Implements Physics::ItoPlasma::ItoPlasmaPhysics.

The documentation for this class was generated from the following files:

Physics/ItoPlasma/PlasmaModels/ItoPlasmaAir3LFA/CD_ItoPlasmaAir3LFA.H
Physics/ItoPlasma/PlasmaModels/ItoPlasmaAir3LFA/CD_ItoPlasmaAir3LFA.cpp
